IES ConcreteBending v8.00.0002

IES ConcreteBending v8.00.0002

36.3 MB

ConcreteBending Specifications

Codes

• IBC, ASCE 7, or NBC load combinations (customizable)
• ACI 318-19 or 14; ACI 350-20 or 06
• CSA A23.3-19, A23.3-14

Modeling

• Elevated slab analysis and design
• Slab & beam systems
• Environmental tank walls
• Complex boundaries, including circular and polygonal templates
• Generate copies of modeling elements using rectangular or circular patterns
• Multiple slab thicknesses
• Holes in concrete
• Wall or beam supports
• Point supports or loads (w/punching shear)
• Automatic FEA mesh generation
• Sophisticated thick-plate finite element formulation
• Import & Export DXF files
• Command-line with scripting programmability

Loading

• Customizable load combinations
• Streamlined seismic load combinations
• Uniform or linear area loads, rectangular or circular
• Circular and rectangular “ring” loads
• Overturning loads
• Column loads, axial and moments
• Linear beam loads
• Wall loads, axial and moments

Designing

• Slab shear plotted and checked
• Slab punching shear checks
• Column and column-group punching shear checks
• Wall punching shear design checks
• Beams are checked for shear, moment, and torsion
• Single or double layer of slab reinforcement
• Size each layer of slab steel
• Reinforcing bar patterns
• Beam checks and reinforcement
• Override for minimum reinforcement
• Export to VisualAnalysis for more complicated tasks

Reporting

• Post-analysis statics check reports
• Full-color reporting for a professional look and easy reading
• Slab and beam moment and shear diagrams
• Preview the report before printing
• Customize what items are included in the report
• Easy export to .xls, .docx, or .pdf file
• Print one-page graphic summaries
