MATLAB-Simulink for Power Electronics Simulation

Learn how to simulate power electronics devices such as rectifiers, dc-to-dc converters and inverters in MATLAB/Simulink

How to simulate power electronics devices in MATLAB/Simulink

Simulation of half-wave and full-wave rectifiers

Simulation of buck, boost, and buck/boost converters

Simulation of single-phase and three-phase inverters

How rectifiers, dc-to-dc converters, and inverters work

How to detee the performance of power electronics devices

How to design power electronics devices to meet certain design specifications

Simulink models provided so you can follow along and use for your own designs

MATLAB/Simulink software, free trial available online

This course not only gives a review of the theory of how rectifiers, dc-to-dc converters, and inverters work, but also gives several examples on how to simulate these devices using MATLAB/Simulink. The course is divided into the following sections:

1. Introduction to MATLAB/Simulink for Power Electronics: in section 2, we will b by reviewing the theory behind the sonductor devices that are used in power electronics, such as diodes, power BJTs, power MOSFETs, IGBTs, and Thyristors. We will then take a look at the libraries available in Simulink to represent these devices in our models. After that, we will take a look at how we can model voltage sources, current sources, and passive components (resistors, capacitors, and inductors), as well as how we can put them together in a model using Simulink and how we can take measurements in the model to ensure proper simulation.

2. Rectifier Simulations: we will b section 3 by reviewing the theory behind the operation and topologies of power electronics rectifiers. We will then see how we can simulate both single-phase and three-phase rectifiers using Simulink.

3. DC-to-DC Converter Simulations: we will b section 4 by reviewing the theory behind the operation and topologies of power electronics dc-to-dc converters. We will then see how we can simulate buck, boost, and buck/boost converters.

As mentioned above, in each section, we will go over several models to illustrate how we can design and simulate power electronics devices in MATLAB/Simulink. The models are also available for so that you can follow along, as well as use these models and modify them to create your own designs.

By learning how to simulate power electronics devices in MATLAB/Simulink, you will be able to further your career in electrical eeering and power electronics.

Remember that Udemy offers a 30-day money-back guarantee. I am also always available for questions while you go through the course to ensure everything is clear.

See you in the course!

Eeering students

Practicing eeers

Anybody with an interest in learning about power electronics and/or MATLAB/Simulink
